Model: LDSP-160D
Application: This plant is design for packing dry powders, such as detergent powder, milk powder, coffee powder, pepper powder, chilli powder, salt powder, sugar powder, flour, corn flour, chemical powder, washing powder, detergent powder, vegetable powder, spice powder, seasoning powder, fruits powder, juice powder, tea powder, etc.
20-45bag/min
Model: LDSP-160D
Application: This plant is design for packing dry powders, such as detergent powder, milk powder, coffee powder, pepper powder, chilli powder, salt powder, sugar powder, flour, corn flour, chemical powder, washing powder, detergent powder, vegetable powder, spice powder, seasoning powder, fruits powder, juice powder, tea powder, etc.
20-45bag/min
● Application:
This plant is design for packing dry powders, such as detergent powder, milk powder, coffee powder, pepper powder, chilli powder, salt powder, sugar powder, flour, corn flour, chemical powder, washing powder, detergent powder, vegetable powder, spice powder, seasoning powder, fruits powder, juice powder, tea powder, etc.
Suitable Pouches: All type of heat sealable preformed side seal bags, fin seal bags, gusseted bags, block bottom bags, zip-lock recloseable bags, stand-up pouch with or without spout ect.
● Kindly Reminder: We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
● 1.The bag-feeding slot is convenient and simple to place bags, and is equipped with an automatic bag-pressing device;
● 2.It is equipped with an imported pressure sensing device to achieve no blanking or sealing;
● 3.Use color touch screen, simple operation, multi-functional design;
● 4.The machine adopts stainless 304L appearance, and the carbon steel frame part and some accessories are processed with acid and salt resistant anti-corrosion treatment layer;
● 5.Material selection requirements: Most of the accessories are formed by mold production, and the main materials are 304 stainless steel and alumina;
● 6.Various coding, coding, exhaust, and punching systems are optional.
| Type | LDSP-160D (Powder packing) | LDSP-160A (Granule packing) | LDSP-160L (Liquid packing) |
| Packing material | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc. | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc. | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc. |
| Bag size | 110-230mm*80-160(L*W) | 110-230mm*80-160mm(L*W) | 110-230mm*80-160mm(L*W) |
| Filling range | 10g-100g | 20g-500g | 10g-100g |
| Packing speed | 20-45bags/min(speed is determined by the product filling quantity) | 20-45bags/min(speed is determined by the product filling quantity) | 20-45bags/min(speed is determined by the product filling quantity) |
| Machine weight | 800KG | 800KG | 800KG |
| Total power(Doypack packing machine) | 2.0KW | 2.5KW | 2.5KW |
| Work flow | 1.Giving bag; 2.Pick up the bag(coding); 3.Open the bag up and down; 4.Filling; 5.Heating sealing; 6.Output of product | 1.Giving bag; 2.Pick up the bag(coding); 3.Open the bag up and down; 4.Filling; 5.Heating sealing; 6.Output of product | 1.Giving bag; 2.Pick up the bag(coding); 3.Open the bag up and down; 4.Filling; 5.Heating sealing; 6.Output of product |
| Dimension(Doypack packing machine) | 1750*1285*1360(L*W*H) | 1750*1285*1360(L*W*H) | 1750*1285*1360(L*W*H) |
● 1.Giving bag;
● 2.Pick up the bag(coding);
● 3.Open the bag up and down;
● 4.Filling;
● 5.Heating sealing;
● 6.Output of product.
After receiving your inquiry, We will send you the quotation as soon as possible.
