Model: LD-420AS
Application: It is suitable for automatic weighing packaging of various fine particle and powder products, such as sugar, salt, seeds, rice, sesame, ,milk, coffee, washing powder, chili powder, spices, soap powder, curry powder, etc.
5-60bag/min
Model: LD-420AS
Application: It is suitable for automatic weighing packaging of various fine particle and powder products, such as sugar, salt, seeds, rice, sesame, ,milk, coffee, washing powder, chili powder, spices, soap powder, curry powder, etc.
5-60bag/min
● Application:
It is suitable for automatic weighing packaging of various fine particle and powder products, such as sugar, salt, seeds, rice, sesame, ,milk, coffee, washing powder, chili powder, spices, soap powder, curry powder, etc.
● Kindly Reminder: We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
● Chinese or English display(Language can be set according to customer requirements).
● Imported PLC control system, colorful touch screen, can clearly shows working state and operation indicator,easy to operate,intuitionistic and efficient.
● New high set according to modular control system.
● Amplitude of automatic adjustment function, debugging more convenient.
● Can weigh a variety of different materials at the same time, the realization of mixed material package.
● According to the production situation can directly modify the parameters in the running, easy operation.
● Adopts stepless vibration machine feed system, make the material more evenly, weighing range greater all adopt the stainless steel materials, clean health.
● With a pneumatic door opener, and can realize the vibration feeding machine will be automatically closed.
● And material contact parts (storage hopper, hopper, vibration plate, weighing hopper, etc.) are to realize fast disassembly, particularly convenient clean.
| Type | LD-420 | LD-520 | LD-620 | LD-720 |
| Film width | Max.420mm | Max.520mm | 150-Max.620mm | 150-Max.720mm |
| Bag length | 80-300mm | 60-400mm | 60-450mm | 60-500mm |
| Bag width | 60-200mm | 100-250mm | 65-300mm | 65-350mm |
| Film roll diameter | Max.600mm | Max.600mm | Max.600mm | Max.600mm |
| Packing speed | 5-60bag/min | 5-40bag/min | 5-35bag/min | 5-30bag/min |
| Making-bag volume | 1000ml | 2000ml | 3000ml | 5000ml |
| Film thickness | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm |  0.04-0.12mm |
| Power Supply | 220V,50/60Hz,3KW | 220V,50/60Hz,3KW | 220V,50/60Hz,3.2KW | 220V,50/60Hz, 3.5KW |
| Machine size(L*W*H) | (L)1217X(W)1015X(H)1343mm | (L)1488X(W)1080X(H)1490mm | (L)1488X(W)1180X(H)1550mm | (L)1780X(W)1350X(H)2050mm |
| Remarks | Optional air filling device/ (Optional gusseting device) | |||
| Film material | BOPP/CPP, BOPP/VMCPP, BOPP/PE, PET/VMPET/PE, PET/AL/PE, PET/PET ETC. | |||
● 1. LD series machine;
● 2. Z type conveyor;
● 3. Finished product conveyor;
● 4. Linear electronic scale.
After receiving your inquiry, We will send you the quotation as soon as possible.
