Model: LD-420A
Film roll diameter: Max.600mm
Making-bag volume: 1000ml
Application: It is suitable for various kinds of dry fruit, apple dried fruits, raisin, nuts, peanuts, candies, seeds, etc.
5-60bag/min
Model: LD-420A
Film roll diameter: Max.600mm
Making-bag volume: 1000ml
Application: It is suitable for various kinds of dry fruit, apple dried fruits, raisin, nuts, peanuts, candies, seeds, etc.
5-60bag/min
●Application: Dry Fruit Packing Machine With Labeling Machine Metal Detector And Weight Selection Scale, it is suitable for various kinds of dry fruit, apple dried fruits, raisin, nuts, peanuts, candies, seeds and such materials in grain or piece as well as powder like milk powder, washing powder, starch, etc.
●Kindly Reminder: We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
●Multi-head combined weigher, improve metering speed and accuracy.
●7inch touch screen, easy operation and multiple language for choice.
●Imported PLC system, machine performance is stable and easy for parameters adjusting.
●With a memory function for storage ten sets of parameters. Easy to change packing product.
●Separate PID temperature controller, suitable for various packing materials.
●Multi-union roll film pulling system make film running more smooth.
●Adopt double servo film-dragging structure, enable stable bag forming for perfect bag shape.
●Sophisticated sealing framework achieve the consistency of bag sealing and cutting.
●Machine automatically finish the process of filling, metering, bag forming, date printing, sealing and packing.
●Low loss, labor saving, easy for operation and maintenance.
●Equipped with a labeling machine, metal detector and a weight selection scale to ensure the safety of packaged products and control weight errors.
| Model | LD-420 | LD-520 | LD-720 | LD-900 | LD-1050 | LD-1200 |
| Film Thickness | 0.04-0.08mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm |
| Bag Length | 80-300mm | 80-350mm | 100-500mm | 100-600mm | 100-800mm | 100-1000mm |
| Bag Width | 60-200mm | 100-250mm | 180-350mm | 260-430mm | 290-505mm | 290-580mm |
| Film Roll Diameter | Max.320mm | Max.320mm | Max.320mm | 400mm | 400mm | 400mm |
| Pakaging Rate | 5-60bag/min | 5-60bag/min | 5-55bag/min | 5-20bag/min | 5-20bag/min | 5-20bag/min |
| Film Width | Max.420mm | Max.520mm | 150-Max.720mm | Max.900mm | Max.900mm | Max.1200mm |
| Measurement Range | 150-1500ml | 5-2000ml | 4000ml | 1-25L | 1-25L | 1.5L-45L |
● ①Multihead Weigher → ②Pulling film → ③coding → ④bag making → ⑤measurement → ⑥filling (inflating) → ⑦sealing (punching) → ⑧cutting → ⑨metal detection → ⑩packaging finished product output.
After receiving your inquiry, We will send you the quotation as soon as possible.
