Model: LP-680B/ 800B
Application: Suitable for pillow packing of conventional items such as hardware accessories parts, soap, bread, pancake, biscuit, cake, rusk, bun, etc.
30-150bag/min
Model: LP-680B/ 800B
Application: Suitable for pillow packing of conventional items such as hardware accessories parts, soap, bread, pancake, biscuit, cake, rusk, bun, etc.
30-150bag/min
● Suitable for pillow packing of conventional items such as hardware accessories parts, soap, bread, pancake, biscuit, cake, rusk, bun, etc.
● Dual frequency conversion control, Bag length can be set and cut in one step,saving time and film.
● Interface features easy and quick setting and operation
● Self failure diagnosis, clear failure display
● High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
● Temperature independent PID control, more suitable for packaging different materials
● Positioned stop function, without sticking knife or wasting film.
● Simple driving system, reliable working, convenient maintenance.
● All control is realized through software,easy for function adjusting and technical upgrade.
| Type | LP-680B | LP-800B |
| Film width | Max 680mm | Max780mm |
| Bag length | 150-560mm | 210-650mm |
| Bag width | 100-260mm | 120-350mm |
| Product height | Max.110mm | Max.130mm |
| Film roll diameter | Max.320mm | Max.320mm |
| Packaging rate | 30-150bag/min | 30-150 bags/min |
| Power | 220V50/60Hz 6KW | 220V50/60Hz 6KW |
| Machine size | (L)4800*（W）1200*（H)1700mm | (L)4800*（W）1200*（H)1700mm |
| Machine quality | 1120KG | 1150kg |
| Film material | OPP、PE、PVC、OPP/CPP、PT/PE、KOP/CPP/ Aluminum Coating Film/ Aluminum Film | |
● 1. 304 stainless steel Rolling bolls conveyor
● 2. End sealing drag chain
● 3. Auxiliary material feeding device
● 4. Material cut prevent device
● 5. Perforating device
● 6. Angle folding device
● 7. Date printer
● 8. Labeling machine
● 9. Thermal transfer code printer
● 10. Air charging system
● 11. Cutting stop
● 12. Prevent empty package.
