Model: LDSP-160A
Application: Suitable for meat paste, seafood, kimchi, raw meat, fish, shrimp, prawn, chicken, etc.
10-45 bags/min
W: 80-160mm
● Application:
* Block material: bean curd cake, fish, eggs, candy, red jujube, cereal, chocolate, biscuit, peanut, etc.
* Granular type: crystal monosodium glutamate, granular drug, capsule, seeds, chemicals, sugar, chicken essence, melon seeds, nut, pesticide, fertilizer, etc.
* Powder type: milk powder, glucose, monosodium glutamate, seasoning, washing powder, chemical materials, fine white sugar, pesticide, fertilizer, etc.
* Liquid/paste type: detergent, rice wine, soy sauce, rice vinegar, fruit juice, beverage, tomato sauce, peanut butter, jam, chili sauce, bean paste, etc.
* Class of pickles, pickled cabbage, kimchi, pickled cabbage, radish, etc.
● Packing Exambers:
● Rapidly change bag specifications in one-click automatic adjustment.
● Single shaft and the CAM design, faster-packing speed, more stable operation, easier maintenance, and defective rate reduction.
● Modular heating, temperature control is more accurate, heating fault has alarm prompt.
● Advanced design ideas, reduce material loss, ensure the stability of operation, and extend the operating life.
● Simple and convenient operation, adopt the advanced PLC+POD (touchscreen) electric control system and man-machine interface.
● Rotary feeding is compatible with irregular products and different sizes.
● Intubated vacuum packaging, packaging integrity is high, and good sealing.
● Can be applied to all kinds of frozen food, meat products, cooked food, etc.
| Model | LDSP-160A |
| Packing material | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc |
| Bag Size | W: 80-160 mm |
| Filling Range | 20-500g |
| Packing Speed | 10-45 bags/min (speed is determined by the product filling quantity) |
| Average precision | ≤±1% |
| Total Power | 2.5KW |
| Weight | 800 KG |
| Main standard parts | 1. Code printer 2. PLC control system 3. Bag opening device 4. Vibration device 5. Cylinder 6. Electromagnetic valve 7. Temperature controller 8. Vacuum pump 9. Inverter 10. Output system |
● Picking up pouches
● Receiving pouches and coding - (optional)
● Filling product
● Sealing pouches
