Model: LD-TS100
Suitable for various plastic tube, aluminum laminated tube sealing of cosmetics, pharmaceuticals, chemicals, food and other industries.
Sealing Dia: 5-50mm
20-40bottle/min
Model: LD-TS100
Suitable for various plastic tube, aluminum laminated tube sealing of cosmetics, pharmaceuticals, chemicals, food and other industries.
Sealing Dia: 5-50mm
20-40bottle/min
● Used in packaging in medicine, daily chemical, food, chemical, cosmetics and other industries, such as ointment, adhesive, AB glue, epoxy glue, skin cream, hair dye, shoe polish, toothpaste and other liquid or paste-like materials filling And the sealing.
Bag Style:
Tube Sealing
Tube Sealing
Tube Sealing
Tube Sealing
Tube Sealing
Tube Sealing
Tube Sealing
Tube Sealing
Tube Sealing
Tube Sealing
Tube Sealing
Tube Sealing
Main Features:
● The machine adopts a fully enclosed dust cover, the machine body is made of SUS304 material, and the appearance is unique and beautiful;
● The replacement of the base is suitable for filling and sealing of various specifications of pipes, the sealing appearance is neat and tidy, and the sealing is firm;
● The photoelectric benchmarking workstation uses high-precision probes, stepping motors and other precise control patterns to be located in the correct position.
● The filling speed and measurement accuracy are convenient and adjustable, with high adjustment accuracy and good stability;
● The machine can be equipped with various filling methods of different specifications to meet the filling requirements of different viscosities;
● The internal heating is heated by Leister hot air gun, and the external water-cooling device is configured to cool down to make the sealing more beautiful;
● The typing station automatically prints the word code on the position required by the process;
● All parts of the machine contacting materials are made of stainless steel SUS304;
● Adopt PLC control system, simple operation, intuitive and convenient, complete functions, stable operation.
● Model: LD-TS100
● Speed: 20-40bottle/min
● Pipe Diameter: Φ10mm-Φ50mm (Customizable)
● Tube Height: 20mm-250mm (Customizable)
● Control system: PLC
● Power supply: 220V、50Hz
● Airconsumption: 0.3m³/min
● Dimension: 2180mm*930mm*1870mm(L*W*H)
● Equipment Material: 304
● Weight: 700KG
Advantages:
● It adopts Ultrasonic sealing machine , good for difference products, Such as food, medical, cosmetic products. It will not hurting the products.
● Overload protection, phase separation protection, power-fail protection.
● Large Ultrasonic output power to ensure the sealing quality of various tube size and material.
● With tube end trimming
● Easy change working mold for difference tube diameter
● Adjustable tube length
● Machine include a gear pump filler( Good filling precision+- 1)
