Model: LD-320D/ 380D
Application: Suitable for packing the fine powder material. Such as coffee powder, spice powder, milk powder, flour, fruits powder, seasoning, chemical medical powder, etc.It integrates metering, bagging, packing, sealing, date printing. Suitable for Various bag types, e.g. back-sealing bag, 3 sides seal bag, 4 sides seal bag, stick bag, linking bags, etc.
35-70bag/min
Model: LD-320D/ 380D
Application: Suitable for packing the fine powder material. Such as coffee powder, spice powder, milk powder, flour, fruits powder, seasoning, chemical medical powder, etc.It integrates metering, bagging, packing, sealing, date printing. Suitable for Various bag types, e.g. back-sealing bag, 3 sides seal bag, 4 sides seal bag, stick bag, linking bags, etc.
35-70bag/min
● Application: Suitable for packing the fine powder material. Such as coffee powder, spice powder, milk powder, flour, fruits powder, seasoning, chemical medical powder, etc.It integrates metering, bagging, packing, sealing, date printing. Suitable for Various bag types, e.g. back-sealing bag, 3 sides seal bag, 4 sides seal bag, stick bag, linking bags, etc.
● High precision structure for simple and easy operating and repairing.
● Single-chip CPU,step-motor,easy and accurate to set the bag length.
● Own simple circuitry and outstanding function.
● Be able to complete the whole procedure of filling,bagging,date printing,charging(exhausting) automatically.
| Model | LD-320D | LD-380D |
| Film width | 120-320mm | 180-380mm |
| Bag length | 50-200mm | 60-280mm |
| Bag width | 50-150mm | 60-180mm |
| Diameter of film roll | Max.300mm | Max.320mm |
| Packing speed | 35-70bag/min | |
| Measuring range | 50-500ml | 50-750ml |
| Film thickness | 0.04-0.07mm | |
| Power | 220V 50/60Hz 2.2KW | 220V 50/60Hz 2.5KW |
| Machine size(L*W*H) | 970*680*1950mm | 1100*800*2150mm |
| Machine weight | About 300kg | About 450kg |
● Date Coder
● Hole Punching Device(Pinhole, Round hole, the butterfly hole)
● Linking bag control device
● Air-filling Device
● Air Exhaust Device
● Tear Notch Device
After receiving your inquiry, We will send you the quotation as soon as possible.
