Model: LD-320L/ 380L
Application: Automatic liquid 3/4 sealing sachet packaging machine, it is suitable for packing for all kinds of liquid material which such as liquid milk, water, honey, juice, tomato paste, ketchup, sauce, oil, etc. After replacing the sealing device, Suitable for Various bag types, e.g. back-sealing bag, 3 sides seal bag, 4 sides seal bag, stick bag, linking bags, etc.
35-70bag/min
Model: LD-320L/ 380L
Application: Automatic liquid 3/4 sealing sachet packaging machine, it is suitable for packing for all kinds of liquid material which such as liquid milk, water, honey, juice, tomato paste, ketchup, sauce, oil, etc. After replacing the sealing device, Suitable for Various bag types, e.g. back-sealing bag, 3 sides seal bag, 4 sides seal bag, stick bag, linking bags, etc.
35-70bag/min
● Application: Automatic liquid 3/4 sealing sachet packaging machine, it is suitable for packing for all kinds of liquid material which such as liquid milk, water, honey, juice, tomato paste, ketchup, sauce, oil, etc. After replacing the sealing device, Suitable for Various bag types, e.g. back-sealing bag, 3 sides seal bag, 4 sides seal bag, stick bag, linking bags, etc.
● Computer PLC control and automatic alarming function.
● Multilingual screen display, easy operation.
● High sensitivity photoelectric eye color tracing,more accuracy.
● Bag type can be customised to 3 or 4 sides sealing bag, pillow bag, long stick bag, link bag, etc.
● Famous brand components, ensure the quality and durability of machine.
● Weight measuring, bag making, filling, sealing, cutting and bags counting can be done automatically.
● Ribbon code printer, link-bag device is option.
● Multipurpose packaging, suitable for various packaging of different product.
| Model | LD-320L | LD-380L |
| Film width | 120-320mm | 180-380mm |
| Bag length | 50-200mm | 60-280mm |
| Bag width | 50-150mm | 60-180mm |
| Diameter of film roll | Max.300mm | Max.320mm |
| Packing speed | 35-70bag/min | |
| Measuring range | 50-500ml | 50-750ml |
| Film thickness | 0.04-0.07mm | |
| Power | 220V 50/60Hz 2.2KW | 220V 50/60Hz 2.5KW |
| Machine size(L*W*H) | 970*680*1950mm | 1100*800*2150mm |
| Machine weight | About 300kg | About 450kg |
● Date Coder
● Hole Punching Device(Pinhole, Round hole, the butterfly hole)
● Linking bag control device
● Air-filling Device
● Air Exhaust Device
● Tear Notch Device
After receiving your inquiry, We will send you the quotation as soon as possible.
