Model: LP-450/ 600/ 700
Application: Suitable for pillow bag packaging of fruits and vegetables such as lettuce, asparagus, celery, garlic, cabbage, Chinese cabbage, peppers, cucumbers, onions, etc.
Film width: Max.700mm
20-150bags/min
Model: LP-450/ 600/ 700
Application: Suitable for pillow bag packaging of fruits and vegetables such as lettuce, asparagus, celery, garlic, cabbage, Chinese cabbage, peppers, cucumbers, onions, etc.
Film width: Max.700mm
20-150bags/min
● Suitable for pillow bag packaging of fruits and vegetables such as lettuce, asparagus, celery, garlic, cabbage, Chinese cabbage, peppers, cucumbers, onions, etc.
Dual frequency conversion control, bag length can be setted and cutting in one step,saving time and films.
Interface features are easy and quick setting and operating.
Self diagnosis failure function, clear failure display.
High sensitivity photoelectric eye color tracing,numerical input of cutting sealing position for extra accuracy.
Temperature independent PID control, more suitable for packing different materials.
Positioned stop function,without sticking knife or wasting film.
Simple driving system,reliable working,convenient maintenance.
All control is realized through software,easy for function adjusting and technical urgrade.
Type | LP-400 | LP-450 | LP-600 | LP-700 |
Film Width | Max.400MM | Max.450MM | Max.600MM | Max.700MM |
Bag Length | 150-400MM | 150-450MM | 160-500MM | 180-600MM |
Bag Width | 50-180mm | 50-180mm | 50-280mm | 100-330MM |
Products High | max.65mm | max.75mm | max.110mm | max.110mm |
Packing Speed | 30-150bag/min | 30-150bag/min | 20-150bag/min | 20-130bag/min |
Power | 220V; 50/60HZ 2.8KW | 220V; 50/60HZ 2.8KW | 220V; 50/60HZ 2.8KW | 220V; 50/60HZ 2.8KW |
Machine Size(mm) | 4020x770x1420 | 4020x820x1420 | 4020x970x1500 | 4030x1070x1500 |
Machine Weight | 600kg | 650kg | 680kg | 720kg |
● Date Coder
● Automatic Punching Device
● Auto labeling device
● Nitrogen generator
